E312-42 |
||
|---|---|---|
| Part Number | E312-20-42-01 | |
| Description |
E3 Circuit Protector (Breaker), Thermal Protector SAE Type 1 Circuit Protector (Breaker) In-Battery Circuit Protector (Breaker) |
|
| Family | Thermal Circuit Protector (Breaker) | |
| Category | E3 | |
| Series | E312 | |
| Voltage | 14Vdc | |
| Rated Current | 20A | |
| Reset Type | T1, Auto Reset | |
| Operating Temperature | -40ºC (-40ºF) to 85ºC (185ºF) | |
| Dimension |
Length: 25.2 Width: 10.0 Height: 27.3 Unit: mm |
|
| Weight | 6 g | |
| RoHS | Y | |
| Standard Pack | 1500 | |
| Termination | QC Terminals | |
| Body | UL-rated 94V0 thermoset plastic | |
| Body Color | Black | |
Length: 25.2
Width: 10.0
Height: 27.3
Unit: mm
